Gearless Machine Room Less Elevator
Product Specifications
|
Parameter |
Value |
|
Product Model |
DKW1000-VF |
|
Product Type |
Gearless Machine Room Less Elevator |
|
Rated Load |
1000 kg |
Core Advantages
Direct Drive Without Gearbox Servicing
The DKW1000-VF uses a permanent-magnet synchronous motor to drive the traction sheave without a reduction gearbox and carries a rated load of 1,000 kg. During repeated passenger journeys, this direct connection removes gear-meshing noise and eliminates gearbox oil changes from the drive's maintenance tasks.
Electrical Energy Recovery
The energy-feedback device returns generated electricity to the building supply during regenerative operation. When the moving car and counterweight drive the motor as a generator, the recovered energy becomes available to building loads instead of being dissipated as braking heat.
Machinery Within the Hoistway
Both the motor and control cabinet sit inside the hoistway. On projects with a restricted roof profile or no allocated machinery-room area, the installation keeps these components within the shaft and removes the need to construct a separate equipment room.
Custom Gearless Machine Room Less Elevators
Dongao manufactures and assembles gearless lifts from project drawings that define the available shaft, landing geometry and selected interior specification.
Customizable Items
- Car width and depth
- Entrance opening dimensions
- Car interior finish
- Landing-door finish
- Operating-panel arrangement
Quality Control
Dongao carries out 100% inspection before packing and accepts third-party inspection of the supplied elevator equipment. The inspection scope follows the confirmed configuration so the selected drive, control package and associated equipment are reviewed as the ordered system.
Electrical and safety acceptance continue after installation. For Dongao installation projects, specialist inspection forms part of the site handover sequence. The complete installed lift is accepted before passenger use, and operating personnel receive training at handover.
FAQ
Q: Can I order a single elevator?
A: Yes. The minimum order quantity is one unit.
Q: How long does standard production take?
A: About one month.
Q: Should passengers use this elevator during a building fire?
A: No. Follow the building's evacuation procedure and use the designated escape routes.
Q: Who should assist passengers if the car stops between floors?
A: Qualified elevator personnel. Passengers should call for assistance and remain inside the car.
